6ES7131-6BF01-0BA0
- Termin płatności do 90 dni od 500+ dostawców.
- Rabaty na odsprzedaż do 40%!
Opis
Additional Information
- Part Number
- 6ES7131-6BF01-0BA0
- UPC
- 804766528088
- Tariff Code
- 8538908180
- Country of Origin
- DE
- ETIM
- Group Code : EG000024
- Group Description : PLC's
- Class Description : Fieldbus, decentr. periphery - digital I/O module
- Class Code : EC001599
- Version : 7
Specifications
- Country of Origin
- DE
- Depth
- 58 mm
- Width
- 15 mm
- Height
- 73 mm
- System accessory
- true
- Supply voltage DC
- 19.2 V
- Number of digital inputs
- 8
- Number of digital outputs
- 0
- Rail mounting possible
- true
- Type of digital output
- None
- Number of HW-interfaces USB
- 0
- Degree of protection (IP)
- IP20
- Input current at signal 1
- 2.5 A
- Number of HW-interfaces other
- 0
- Number of interfaces PROFINET
- 0
- Permitted voltage at input
- -30 V
- Digital inputs configurable
- true
- Number of HW-interfaces RS-232
- 0
- Number of HW-interfaces RS-422
- 0
- Number of HW-interfaces RS-485
- 0
- Voltage type of supply voltage
- DC
- Number of HW-interfaces Wireless
- 0
- Number of HW-interfaces parallel
- 0
- Type of voltage (input voltage)
- DC
- Number of HW-interfaces serial TTY
- 0
- Time delay at signal exchange
- 0.05 ms
- Explosion safety category for dust
- None
- Number of HW-interfaces industrial Ethernet
- 0
- Type of electric connection
- Plug-in connection
- Fieldbus connection over separate bus coupler possible
- true
- Explosion safety category for gas
- ATEX gas-ex-protection, Cat. 3G
Powiązane produkty
Dodatkowe informacje
The Siemens 6ES71316BF010BA0 is a Simatic S7-300 digital input module used in industrial automation applications. This module is equipped with 16 digital inputs with a voltage range of 24VDC. It has a protection category of IP20 and a maximum switching frequency of 20kHz. This module is part of the ET 200S product range and has a width of just 22.5mm, making it well suited for space-constrained industrial applications.
The 6ES71316BF010BA0 is designed to be used with the Simatic S7-300 series industrial controllers. It is compatible with all S7-300 CPUs and can be connected to the CPU via the Profibus DP network. It is also compatible with the Siemens HMI software packages for visualizing the data from the module. The module is equipped with an LED display to provide the user with an indication of the module's operational status.
The 6ES71316BF010BA0 is designed to provide reliable and accurate digital input readings in industrial applications. It has a wide range of input voltage options, as well as an advanced protection mechanism to ensure that the module remains safe and reliable in harsh industrial environments. The module is also designed to be easy to integrate into the system, thanks to its compatibility with the S7-300 series controllers and the wide range of software options available.
