Brady Corporation
PS-125-2-WT-S
PermaSleeve Polyolefin Wire Marking Sleeves, White, 0.125" Dia x 2" W, Roll of 500 Each
- Ottenete termini di pagamento fino a 90 giorni da 500+ fornitori.
- Sconti sulla rivendita fino al 40%!
€292.90
1
Metodi di pagamento:
Un totale di 2.000 Parts In-Stock da 2 Distributors
Condizioni del prodotto:
Additional Information
- Part Number
- PS-125-2-WT-S
- UPC
- 662820321439
- UNSPSC
- 55121612
Specifications
- Applications
- Wire and Cable Labeling
- Brand Name
- Brady®
- Color
- White
- Enables Industry Compliance
- ASTM D 2671; ASTM E 162; ASTM E 662; ASTM G 155; MIL-STD-202; SAE-AMS-DTL-23053; SAE-AS-81531; UL Recognized
- Finish
- Matte
- For Use with Printer
- BBP®72 Label Printer; BRADY IP® Series Label Printer; BradyPrinter i5100; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer
- Label/Media Format
- Roll
- Markers per Roll
- 500
- Primary Noun, Basic Function
- Sleeve
- Print Technology
- Thermal Transfer
- Printable Sides
- Single-Side Printable
- Printer and Label Applications
- Wire & Cable
- Printer Compatibility
- BBP12; BBP11; BBP72; IP300; IP600; PR200Plus; PR300Plus; PR600Plus; i7100; i5100
- Printer Compatibility (Print)
- BBP12; BBP72; i7100; i5100
- Quantity per Roll
- 500
- Quantity per Row
- 1
- Recommended Ribbon
- IP-R6600; R6600
- Ribbon Series
- R6600
- Shape
- Rectangle
- Shrink Ratio
- 3:1
- Suggested Ribbon Series
- R4300; R4502S; R5000; R6600; R6700
- Total Qty per Pack
- 500 Sleeve(s) / Roll
- Total Quantity
- 500
- Trade Name
- PermaSleeve®
- Brady Material Number
- B-342
- Label Properties
- Heat Shrink Sleeves
- Material
- Heat-shrink Polyolefin
- Material Properties
- Flame-retardant; Heat-shrinkable
- Resistance Properties
- Chemical-Resistant; Corrosion-Resistant; Humidity-Resistant; Smear-Resistant; UV-Resistant; Weather-Resistant
- SAP B-Number
- B-342
- Core Diameter (mm/cm/m)
- 76.20 mm
- Diameter as Supplied (in/ft/yd)
- 0.125 in
- Diameter as Supplied (mm/cm/m)
- 3.2 mm
- Dimensions
- 0.235 in H
- Dimensions (Metric)
- 50.80 mm W x 6.00 mm H
- Dimensions 2
- 0.235 in H
- Height (in/ft/yd)
- 0.235 in
- Height (mm/cm/m)
- 6.00 mm
- Maximum Service Temperature °C
- 135 °C
- Maximum Service Temperature °F
- 275 °F
- Maximum Wire Diameter (in/ft/yd)
- 0.11 in
- Maximum Wire Diameter (mm/cm/m)
- 2.79 mm
- Maximum Wire Gauge
- 16 AWG
- Minimum Service Temperature °C
- -55 °C
- Minimum Service Temperature °F
- -67 °F
- Minimum Wire Diameter (in/ft/yd)
- 0.046 in
- Minimum Wire Diameter (mm/cm/m)
- 1.17 mm
- Minimum Wire Gauge
- 22 AWG
- Recovered Diameter (in/ft/yd)
- 0.046 in
- Recovered Diameter (mm/cm/m)
- 1.2 mm
- Roll Width (in/ft/yd)
- 2 in
- Roll Width (mm/cm/m)
- 50.8 mm
- Size - Width (mm)
- 50.80 mm
- Sleeve Size (in/ft/yd)
- 0.125 in Dia x 2 in W
- Sleeve Size (mm/cm/m)
- 3.2 mm Dia x 50.8 mm W
- Sleeve Width (in/ft/yd)
- 2 in
- Sleeve Width (mm/cm/m)
- 50.8 mm
- Vertical Repeat
- 0.5 in
- Vertical Repeat (mm)
- 12.70 mm
- Web Width (mm/cm/m)
- 89.00 mm
- Wire Diameter Range
- 0.046 in to 0.11 in
- Wire Gauge Range
- 22 AWG to 16 AWG
Regulatory Information
- CA Prop 65 Labeled
- Yes
- CA Prop 65 Label Warning
- WARNING: Cancer - www.P65warnings.ca.gov
- Contains CA PROP 65 Substance
- Yes Contains-Label required
- Contains CA PROP 65 Substance
- Yes
- Contains CA PROP 65 Warning Type
- Cancer
- Contains CA Prop 65 Cancer Causing Chemical
- Antimony Trioxide
- Contains Heavy Metal(s)
- No - Does not contain
- DOT Regulated Product
- No = not regulated by DOT
- EU RoHS Compliance
- Pass 2011/65/EU(Pass 2015/863)
- EU RoHS Compliant
- Yes
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
