Schneider Electric BMEH586040

The Modicon M580 Redundant Processor Module is an advanced solution designed for medium to large-scale industrial automation systems. This module, part of the Modicon M580 range, offers a maximum of 1 rack configuration and supports up to 64 distributed equipment.

This redundant processor module is equipped with a current consumption of 295mA at 24V DC, making it an efficient choice for power-sensitive applications. It integrates Ethernet TCP/IP for service port, 2 Ethernet TCP/IP for device network, Ethernet for HSBY port and USB type mini B for connections.

The module is designed to offer high reliability with a Mean Time Between Failures (MTBF) of 600000 hours. It comes with an integrated RAM of 64MB for program and data, 10kb for system memory, and an expandable flash of 4GB for data storage.

This IP20 rated product is suitable for a wide range of industrial applications and is certified by CE, Merchant Navy, UL, RCM, CSA, EAC. It meets the EN 61131-2, EN 61000-6-4, EN 61000-6-2, and EN 61010-2-201 standards.

The Modicon M580 offers numerous benefits including reduced time to market, improved reliability and sustainability, enhanced productivity with high performance, and increased operating profitability due to improved access to data.
