Schneider Electric CA4KN31SW3

The control relay features a composition of 4 contacts, including 3 normally open (NO) and 1 normally closed (NC) contact, with a maximum operational voltage of 690V and a control circuit voltage of 72V DC. It is designed for the control of electromagnetic loads categorized under AC-15 and DC-13, ensuring reliable operation in various applications.

Constructed with a low consumption coil, the device incorporates an integral suppression device, utilizing a bi-directional peak limiting diode to enhance durability. It is capable of achieving high operating rates of up to 180 cycles per minute, functioning effectively within an ambient temperature range of -25 to +50°C. The relay's compact dimensions of 45mm in width allow for easy installation on a 35mm DIN rail or via screw mounting.

This product meets multiple standards including IEC, UL, CSA, CCC, and EAC, confirming its compliance with international safety and performance requirements. The control relay is built to withstand various mechanical stresses, with a vibration tolerance of 2 Gn when open and 4 Gn when closed, and shock resistance of up to 15 Gn for closed contacts.

In terms of sustainability, this relay is compliant with RoHS directives, is mercury-free, and adheres to environmental regulations. It also features a minimum switching current of 5 mA and has a mechanical durability rated for 30 million cycles.
