Schneider Electric LC1K09004F7

The contactor features 4 poles (4NO) and is designed for controlling non-inductive loads with a maximum capacity of 20A at a rated operational voltage of 690V AC-1. It operates with a coil voltage of 110V AC at a frequency of 50/60Hz and is equipped with screw clamp terminals for electrical connections. The device provides reliable operation with a mechanical durability rated at 10 million cycles and an electrical durability of 0.16 million cycles at 20A AC-1.

With a compact design measuring 45mm in width, this contactor can be mounted on a DIN rail or directly onto a plate. It supports an operating rate of up to 3600 cycles per hour and is suitable for environments with ambient temperatures reaching up to 50°C. Notably, it is compliant with multiple international standards including IEC, UL, and CSA, and adheres to Green Premium standards, ensuring it is free from hazardous substances.

The contactor is built to withstand mechanical shocks and vibrations, conforming to IEC 60068 standards. It operates effectively up to an altitude of 2000 meters without derating. Its IP degree of protection is IP2X, providing a level of protection against solid objects. The product is designed to ensure long-term reliability and durability in standard applications.
