Siemens
6ES7414-2XL07-0AB0
CPU414-2. MPI/DP. 2 MB
- Ottenete termini di pagamento fino a 90 giorni da 500+ fornitori.
- Sconti sulla rivendita fino al 40%!
£3,939.10
1
Metodi di pagamento:
Un totale di 128 Parts In-Stock da 34 Distributors
Condizioni del prodotto:
Descrizione
AttivoConforme a RoHS
SIMATIC S7-400. CPU 414-2 CENTRAL PROCESSING UNIT WITH: 2 MB WORKING MEMORY. (1 MB CODE. 1 MB DATA). 1. INTERFACE MPI/DP 12 MBIT/S. 2. INTERFACE PROFIBUS DPAdditional Information
- Part Number
- 6ES7414-2XL07-0AB0
- UPC
- 804766336621
- Tariff Code
- 8537109160
- Country of Origin
- DE
- ETIM
- Group Code : EG000024
- Group Description : PLC's
- Class Description : PLC CPU-module
- Class Code : EC000236
- Version : 7
Specifications
- Country of Origin
- DE
- Width
- 25 mm
- Depth
- 219 mm
- Height
- 290 mm
- Model
- Modular
- Redundancy
- true
- Type of memory
- RAM
- Memory size
- 2000 kByte
- System accessory
- true
- Number of relay outputs
- 0
- Number of digital inputs
- 0
- Number of analogue inputs
- 0
- Number of digital outputs
- 0
- Number of analogue outputs
- 0
- Number of HW-interfaces USB
- 0
- Number of HW-interfaces RS-232
- 0
- Number of HW-interfaces RS-485
- 2
- Voltage type of supply voltage
- DC
- Number of HW-interfaces Wireless
- 0
- Number of HW-interfaces parallel
- 0
- Supporting protocol for PROFIBUS
- true
- Explosion safety category for dust
- None
- Processing time (1K, binary operation)
- 0.01875 ms
- Explosion safety category for gas
- ATEX gas-ex-protection, Cat. 3G
