BMXAMO0410

Name: analog isolated high level output module, Modicon X80, 4 outputs, 0 to 20mA, 4 to 20mA, 10V positive or negative
Brand: Schneider Electric
SKU: BMXAMO0410
Availability: InStock

1 / 5

Descripción

Activo maduro

This product is part of the Modicon X80 range, a common platform of modules for Modicon M580 and M340 Programmable Automation Controllers (PAC). This isolated analogue output module has 4 outputs with 15bit + sign resolution. It is an output module which work with internal power supply via rack. This product is robust, high quality and based on the latest innovative technology. It is furnished with 20-way connector for electrical connection. It is an IP20 rated product. It weighs 0.15kg. It is suitable for medium to large process applications. This product is certified by EAC, Merchant Navy, CSA, RCM, CE and UL. It meets EN 61131-2, EN 61000-6-4, EN 61000-6-2 and EN 61010-2-201 standards. Modicon X80 consists in a compatible modules common platform that reduce maintenance and training costs with same spare parts in stock, and unique training for different Programmable Automation Controllers (PAC).

Country of Origin: FR
Part Number: BMXAMO0410
Tariff Code: 85389099
EAN: 3595864081571
UNSPSC: 32151705

€371.36

net

€422.00

Envío gratis!

Métodos de pago:

Mejor oferta de:: Proveedor de confianza de Automa.Net
Disponibilidad:: 3 piezas
En stock
Actualizado en: 07-11-2024
Garantía:: 24 meses
Entrega Estimada:: 11 noviembre a Reino Unido
Condición:: Nuevo Precintado de Fábrica

Nuevo Precintado de Fábrica - Un artículo completamente nuevo, sin usar, sin abrir, sin daños, en su embalaje original sellado por el fabricante.

Un total de 14 Parts In-Stock de 2 Distributors

Entrega desde:: NL
CZ

Información de envío

Proceso de Pago Seguro

Políticas de Devolución y Reembolso

Políticas de Envío

Políticas de Garantía

Ofertas Disponibles (1)

Ofertas en stock

Schneider Electric

BMXAMO0410

Condición:: Nuevo Precintado de Fábrica
Disponible:: 11 piezas
En stock
Actualizado en: 07-11-2024

Oferta de:: Proveedor de confianza de Automa.Net
Entrega Estimada:: 08-11 noviembre a Reino Unido
Garantía:: 24 meses

€466.04

€419.43

net

Envío desde:

€25.00

Environment

Product Certifications: CE || RCM || CSA || EAC || Merchant Navy || UL
Ambient Air Temperature For Operation: 0-60 °C
Standards: EN/IEC 61010-2-201 || EN/IEC 61131-2 || UL 61010-2-201 || CSA C22.2 No 61010-2-201
Shock Resistance: 30 gn
Vibration Resistance: 3 gn
Directives: 2014/35/EU - low voltage directive || 2014/30/EU - electromagnetic compatibility
Ambient Air Temperature For Storage: -40-85 °C
Relative Humidity: 5-95 % 55-55 °C without condensation
Ip Degree Of Protection: IP20

Contractual warranty

Warranty: 18 months

Offer Sustainability

Rohs Exemption Information: Yes
Mercury Free: Yes
Reach Regulation: Reference contains Substances of Very High Concern above the threshold
California Proposition 65: WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation: X
Eu Rohs Directive: Pro-active compliance (Product out of EU RoHS legal scope)

Complementary

Mtbf Reliability: 1000000 H
Fallback Mode: configurable || predefined
Measurement Error: <= 0.2 % of full scale 0...60 °C || 0.1 % of full scale 25 °C
Maximum Conversion Value: 0...21 mA 0...20 mA || 0...21 mA 4...20 mA || +/- 10.5 V +/- 10 V
Status Led: 1 LED (Green) RUN || 1 LED per channel (Green) channel diagnostic || 1 LED (Red) ERR || 1 LED (Red) I/O
Temperature Drift: 45 ppm/°C +/- 10 V || 45 ppm/°C 0...20 mA || 45 ppm/°C 4...20 mA
Analogue Output Type: current 0...20 mA || current 4...20 mA || voltage +/- 10 V
Common Mode Rejection: 100 dB
Output Level: high level
Supply: internal power supply via rack
Current Consumption: 150 mA 3.3 V DC || 140 mA 24 V DC
Minimum Crosstalk Attenuation: 80 dB
Net Weight: 0.15 kg
Isolation Voltage: 1400 V DC between channels and ground || 1400 V DC between channels and bus || 750 V DC between channels
Analogue Output Number: 4
Power Consumption In W: 3 W 24 V DC typical || 3.6 W 24 V DC maximum || 0.45 W 3.3 V DC typical || 0.51 W 3.3 V DC maximum
Load Impedance Ohmic: >= 1000 Ohm +/- 10 V || <= 500 Ohm 0...20 mA || <= 500 Ohm 4...20 mA
Detection Type: open circuit 0...20 mA || open circuit 4...20 mA || short circuit +/- 10 V
Operating Altitude: 0...6561.68 ft (0...2000 m) || 2000...5000 m with derating factor
Analogue Output Resolution: 15 bits + sign
Conversion Time: <= 1 ms

Specifications

Range Of Product: Modicon X80
Product Or Component Type: analog output module
Electrical Connection: 20 ways 1 connector
Input Output Isolation: isolated

Productos relacionados

Información adicional

Schneider Electric BMXAMO0410 is a high-performance industrial automation module designed for use in a wide range of applications. This 4-axis stepper motor controller is ideal for controlling multiple motors simultaneously, allowing for precise control and rapid response times. It features a wide range of input/outputs, allowing it to be integrated into almost any system.

The BMXAMO0410 is equipped with a powerful 32-bit microprocessor and advanced motor control algorithms. It is designed to operate efficiently in harsh industrial environments, with an operating temperature range from -10°C to +55°C. It has an integrated safety system that monitors the motor signals and reacts quickly if an anomaly is detected.

The BMXAMO0410 is a robust and reliable solution for industrial automation applications. It is easy to install and configure, and can be integrated into most existing control systems. With its high-performance features, it is the perfect choice for applications that require fast and accurate control of multiple motors.
