ABB 2CSF204101R2800

The F204 A-80/0.1 residual current circuit breaker is designed to safeguard both personnel and equipment from earth fault currents. It operates within a rated operational voltage of 230/400 V AC and complies with IEC/EN 61008 and UL 1053 standards. The device features a four-pole design, ensuring comprehensive protection in various installations.

With an impressive rated conditional short-circuit current of 10 kA and a mechanical endurance rated at 20,000 cycles, this RCCB is suitable for demanding environments. It supports a wide ambient temperature range from -25°C to 55°C, making it versatile for different applications.

The mounting type is DIN-Rail, allowing for easy installation, while its compact dimensions—70 mm wide, 85 mm high, and 69 mm deep—enable efficient use of space in control cabinets. Additionally, the RCCB offers auxiliary contact options and can handle various connection types, including busbars and rigid or flexible wires.

For environmental considerations, it adheres to the RoHS directive and features a recyclability rate of over 82%, supporting sustainable practices.
