Schneider Electric
9001KA5
- Condizione:
- Nuove eccedenze
- Disponibile:
- 1 pz.DisponibileAggiornato il: 04-11-2024
- Offerta da:
Fornitore Automa.Net di fiducia- Consegna stimata:
- Su richiesta
- Garanzia:
- 12 mesi
1
Schneider Electric
9001KA5
1 / 5
Descrizione
Attivo maturo
30mm push button range is robust and offers long term reliability in heavy duty industrial applications and extreme environments. The 9001K operator have a metal operator base and the 9001SK operators have a plastic base. This very broad line of push button operators includes push buttons, emergency stop mushroom head push buttons, selector switches, key operated switches, and operators with potentiometers. Also includes pilot lights (LED, incandescent and neon), joystick controllers, wobble stick operators, and operators with multiple functions. These operators can be purchased as complete operators or as subassemblies that can be assembled by the user to meet specific requirements. The 9001 K metal 30mm push buttons are automatic selfgrounding operators requiring no additional wiring and are ABS Certified. Its protection index is IP20, protecting operators from unexpected contact with live circuits. Contact blocks have terminal screw shipped back out to speed wiring and has a very large variety of accessories. Some operators have super bright LEDs for high visibility. These operators are IP 66, NEMA 4 rated (heavy duty, oil tight, water proof and dust tight without requiring boots). The 9001SK operators are also NEMA 4X corrosion resistant. The 9001K and 9001SK 30mm push button operators conforms to IEC, UL, CSA, EN and NOM standards. They are CE marked. 30mm Push Buttons are used in the automotive, machine tool, crane and hoist, food and beverage, industrial applications, material handling, petrochemical, wastewater treatment, metallurgy and many more industries.- Country of Origin
- FR
- Part Number
- 9001KA5
- Tariff Code
- 85365080
- EAN
- 785901880103
- UPC
- 785901880103
- UNSPSC
- 39121522
$17.54
net1
Metodi di pagamento:
- Migliore offerta da:
Fornitore Automa.Net di fiducia- Disponibilità:
- 10 pz.DisponibileAggiornato il: 04-11-2024
- Garanzia:
- 12 mesi
- Consegna stimata:
- Su richiesta
- Condizione:
- Nuove eccedenze
Nuove eccedenze - Un articolo nuovo, inutilizzato e non danneggiato senza garanzia del produttore. L'articolo può arrivare senza confezione originale o in una confezione sostitutiva. Se fornita, la scatola potrebbe essere stata aperta.
Un totale di 11 Parts In-Stock da 2 Distributors
Processo di Pagamento Sicuro
Politiche di Reso e Rimborso
Politiche di Spedizione
Politiche di Garanzia
Offerte Disponibili (1)
Offerta con tempi di consegna del produttore
Spedizione in:Su richiesta
Miglior prezzo:
€4.13
Environment
- Product Certifications
- NEMA || UL 508
- Ambient Air Temperature For Operation
- -25-70 °C
- Standards
- IEC 60947-5-1 || UL 508 || IEC 60947-5-4 || CSA C22.2 No 14 || JIS C 4520 || IEC 60947-1 || JIS C 852 || UL 60947-5-1
- Shock Resistance
- 50 gn IEC 60068-2-27
- Vibration Resistance
- 7 gn 2-500 Hz)IEC 60068-2-6
- Ip Degree Of Protection
- IP20 IEC 60529
- Ambient Air Temperature For Storage
- -40-70 °C
- Electrical Shock Protection Class
- class II IEC 61140
- Protective Treatment
- TC
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Mercury Free
- Yes
- Environmental Disclosure
- ENVPEP121006EN
- Sustainable Offer Status
- Green Premium product
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation
- X
- Circularity Profile
- N/A
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
Complementary
- [Us] Rated Supply Voltage
- 0...600 V
- Connections - Terminals
- screw-clamp terminals
- Terminals Description Iso N°1
- (3-4)NO_CL
- Short-Circuit Protection
- 10 A cartridge fuse IEC 60947-5-1
- Contacts Material
- silver alloy contacts
- Positive Opening
- with IEC 60947-5-2
- [Ith] Conventional Free Air Thermal Current
- 10 A
- Rated Breaking Capacity
- 3 kA 240 V AC-15, 720 VA || 6 kA 120 V AC-15, 720 VA || 1.2 kA 600 V AC-15, 720 VA || 1.5 kA 480 V AC-15, 720 VA || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
- Net Weight
- 0.023 kg
- [Uimp] Rated Impulse Withstand Voltage
- 2.5 kV IEC 60947-1
- Connections - Terminals
- screw clamp terminals, 1 x 0.22...2 x 2.5 mm² IEC 60947-1
- [Icm] Rated Short-Circuit Making Capacity
- 12 kA 600 V AC-15, 7200 VA || 15 kA 480 V AC-15, 7200 VA || 30 kA 240 V AC-15, 7200 VA || 60 kA 120 V AC-15, 7200 VA || 0.55 kA 125 V DC-13 || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13
- Contacts Type And Composition
- 1 NC
- [Ui] Rated Insulation Voltage
- 250 V 3)IEC 60947-1
- [Ie] Rated Operational Current
- 3 A 240 V, AC-15, A600-Q600 NEMA || 0.55 A 125 V, DC-13, A600-Q600 NEMA
- Contact Operation
- late-break
- Tightening Torque
- 0.8-0.8 N.m IEC 60947-1
- Shape Of Screw Head
- cross slotted
Specifications
- Range Of Product
- Harmony 9001K || Harmony 9001SK
- Product Or Component Type
- contact block
- Device Short Name
- 9001K
