Schneider Electric
GVAED101
1 / 2
Descrizione
Attivo maturo
TeSys Deca auxiliary contact block, for contactors LC1D, LC1F and control relays CAD. It provides 2NO contacts rated up to 10A 690V AC, On-delay setting range 10-180s Clip-on front mounting, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHs/Reach).- Country of Origin
- CZ
- Part Number
- GVAED101
- Tariff Code
- 85365080
- EAN
- 3389119405478
- UNSPSC
- 39121522
Metodi di pagamento:
- Migliore offerta da:
Fornitore Automa.Net di fiducia- Disponibilità:
- 2 pz.DisponibileAggiornato il: 22-11-2024
- Garanzia:
- 12 mesi
- Consegna stimata:
- Su richiesta
- Condizione:
- Nuovo sigillato in fabbrica
Nuovo sigillato in fabbrica - Un articolo nuovo di zecca, inutilizzato, non aperto, non danneggiato, nella sua confezione originale sigillata dal produttore.
Informazioni sulla spedizione
Processo di Pagamento Sicuro
Politiche di Reso e Rimborso
Politiche di Spedizione
Politiche di Garanzia
Environment
- Product Certifications
- UKCA
- Environmental Characteristic
- normal environment
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Mercury Free
- Yes
- Environmental Disclosure
- ENVPEP2207006
- Sustainable Offer Status
- Green Premium product
- Toxic Heavy Metal Free
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Reach Free Of Svhc
- Yes
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Circularity Profile
- ENVEOLI2207006
- Eu Rohs Directive
- Compliant
Complementary
- Minimum Switching Current
- 5 mA
- Height
- 11 mm
- [Ith] Conventional Free Air Thermal Current
- 2.5 A
- [Ue] Rated Operational Voltage
- 24...240 V AC || 24...60 V DC
- Protection Type
- GB2CB... circuit breaker || gG fuse 10 A
- Net Weight
- 0.05 kg
- [Ui] Rated Insulation Voltage
- 600 V UL 508 || 690 V IEC 60947-1 || 600 V CSA C22.2 No 14
- Minimum Switching Voltage
- 17 V
- Tightening Torque
- 1.4 N.m screw clamp terminals
- Rated Operational Power In Va
- 300 VA 48-48 V AC-15 100000 cycles || 400 VA 690-690 V AC-15 100000 cycles || 500 VA 110-127 V AC-15 100000 cycles || 500 VA 500-500 V AC-15 100000 cycles || 650 VA 440-440 V AC-15 100000 cycles || 720 VA 230-240 V AC-15 100000 cycles || 850 VA 380-415 V AC-15 100000 cycles
- Mechanical Durability
- 100000 cycles
- Width
- 45 mm
- Depth
- 29 mm
- Rated Operational Power In W
- 120 W 240 V DC-13 100000 cycles || 140 W 110 V DC-13 100000 cycles || 140 W 24 V DC-13 100000 cycles || 180 W 60 V DC-13 100000 cycles || 240 W 48 V DC-13 100000 cycles
Specifications
- Product Or Component Type
- auxiliary contact block
- Range
- TeSys || TeSys Deca
- Mounting Location
- front side
- Pole Contact Composition
- 2 NO
- Quantity Per Set
- set of 1
- Product Compatibility
- GV3P || GV3L
- Auxiliary Contacts Operation
- fault signal 1 NO
- Device Short Name
- GVAED
