Siemens 3VA2163-6HL32-0AA0

The 3VA21 molded case circuit breaker features a three-pole configuration and an electronic trip unit (ETU320) designed for line protection. With a rated current of 63A and a notable short-circuit breaking capacity of 85kA at 415V, it is suitable for various industrial applications. The device is constructed with a high breaking capacity (Class H) and complies with IEC standards, ensuring reliable performance.

Measuring 4.1 inches in width, 7.1 inches in height, and 4.2 inches in depth, this circuit breaker is designed for easy installation with its front-side connection for the main current circuit. It supports screw connections and is compatible with a nut keeper kit for secure mounting. The unit is rated for a maximum operational voltage of 690V and can function effectively within a temperature range of -25 °C to 70 °C.

Additional features include an overload protection setting adjustable between 25A and 63A, and the capability to accommodate optional motor drives. The product is manufactured under the Siemens Eco Profile standards, emphasizing its environmentally responsible design.
