Weidmuller 1133620000

The DRL570012L relay is designed with four CO contacts utilizing AgCdO material, supporting a rated control voltage of 12 V DC and a continuous current capacity of 10 A. It features flat blade connections measuring 4.8 mm x 0.5 mm.

With a compact size of 41.5 mm in width, 28 mm in height, and 36 mm in depth, this relay weighs 65 g. The device operates effectively within a temperature range of -25 °C to 55 °C and can function under relative humidity levels from 35% to 85%.

The relay has a mechanical service life rated for 10 million switching cycles and achieves a contact resistance of ≤ 50 mΩ. Its dielectric strength between input and output is rated at 2 kVeff for one minute, ensuring reliable operation under varying conditions.

Compliance with standards such as IEC 61810-1 and UL 508 is affirmed through its certification, and it features a green LED status indicator for operational visibility. Notably, the relay is rated for a maximum switching voltage of 250 V AC with a resistive AC switching capacity of 2500 VA and a DC switching capacity of 240 W at 24 V. The inrush current is 50 A for 50 ms, with a minimum switching power of 100 mA at 12 V.

This relay is suitable for applications requiring precise control and robust performance, making it an essential component in various industrial settings.
