Weidmuller 1147370000

This PCB plug-in connector is designed for board connection with a pitch of 5.08 mm and features five poles, each equipped with a single solder pin measuring 3.2 mm in length. The connector's design includes a 90° outgoing elbow, making it suitable for various applications where space constraints are a factor.

Constructed from PA GF insulating material, this connector is orange in color and adheres to insulation group II standards. It is rated for a voltage of 300 V under UL 1059 for both use groups B and D, with a maximum rated current of 18.5 A for group B and 10 A for group D. The connector is suitable for operating temperatures ranging from -50 °C to 100 °C and can be stored within a temperature range of -25 °C to 55 °C.

With a Comparative Tracking Index (CTI) of ≥ 550, it meets stringent insulation requirements and has a UL 94 flammability rating of V-0. This model is approved by cURus and has a certified UL File Number E60693. The connector's construction allows for an insulation strength of ≥ 108 Ω, ensuring reliable performance in demanding environments.
