Weidmuller 1148630000

The SL 5.08HC/02/180G 3.2SN BK BX is designed as a PCB plug-in connector with a male header. It provides a closed side configuration and utilizes a THT solder connection with a pitch of 5.08 mm. This connector supports two poles and has a solder pin length of 3.2 mm, making it suitable for a variety of PCB applications.

With a rated voltage of 300 V in both Use group B and D according to UL 1059, it handles a rated current of up to 18.5 A under Use group B conditions. The connector complies with IEC standards, ensuring a rated current of 24 A at 20°C for the minimum number of poles. It also has an impressive insulation strength of ≥ 108 Ω and a Comparative Tracking Index (CTI) of ≥ 550.

Constructed from PA GF insulating material and finished in black, this product meets various international standards, including cURus and KEMAKEUR approvals. It is suitable for operating temperatures ranging from -50°C to +100°C, with a maximum storage temperature of 55°C. The packaging comes in a box with dimensions of 40 mm in length, 70 mm in width, and 165 mm in height.
