Weidmuller 1150540000

The SL 5.08HC/20/90LF 3.2SN BK BX is a male header PCB plug-in connector designed for THT solder connections, featuring a 5.08 mm pitch and a total of 20 poles arranged at a 90° angle. Each solder pin measures 3.2 mm in length and is tinned for optimal conductivity.

Rated for a voltage of 300 V and a maximum current of 18.5 A (Group B) according to UL 1059 standards, this connector is certified under cURus and EAC, ensuring compliance with international safety standards. The connector is constructed from PA GF insulating material and comes in a black color, aligning with RAL 9011 specifications. Its insulation strength exceeds 108 Ω, with a Comparative Tracking Index (CTI) of ≥ 550, making it suitable for a range of applications.

Dimensions of the connector include a width of 111.4 mm, height of 11.7 mm, and depth of 12 mm, with a net weight of 8.322 g. It operates effectively in temperatures ranging from -50 °C to 100 °C. The connector is designed for a maximum plugging force of 10 N and a pulling force of 7.5 N per pole, ensuring reliable connections.
