Weidmuller 1154840000

The SL 5.08HC/09/90B 3.2SN OR BX is a male header PCB plug-in connector designed for board connections using a THT solder method. This component features a pitch of 5.08 mm and accommodates up to 9 poles. The solder pin length measures 3.2 mm, providing reliable connectivity for various applications.

Constructed from high-quality insulating material PA GF, this connector is identified by its orange color and offers a Comparative Tracking Index (CTI) of ≥ 550. The operating temperature range spans from -50 °C to 100 °C, ensuring functionality in diverse environments. It is compliant with multiple standards, including IEC 60664-1 and IEC 61984, with a rated voltage of 400 V for surge voltage class II/2 and a rated current of 24 A for the minimum number of poles at a temperature of 20 °C.

Additional specifications include a UL 94 flammability rating of V-0 and a GWFI of 960 °C. The connector's dimensions are 47.48 mm in width, 11.7 mm in height, and 12 mm in depth, with a net weight of 3.64 g. It is packaged in a box with specific dimensions to ensure secure storage and transport.

For applications requiring high reliability, this connector supports a maximum plugging force of 10 N per pole and a pulling force of 7.5 N per pole, with an estimated lifespan of 25 plugging cycles. The product family is part of the OMNIMATE Signal - series BL/SL 5.08, making it suitable for various industrial uses.
