Weidmuller 1290530000

The S2C-SMT 3.50/26/180G 1.5SN BK BX is a male header PCB plug-in connector designed for THT/THR solder connections with a pitch of 3.5 mm and 26 poles. This connector features a solder pin length of 1.5 mm and is constructed from LCP GF insulating material, offering a high Comparative Tracking Index (CTI) of ≥ 175, which enhances its performance in various applications.

With a rated voltage of 150 V (Use group B) and 50 V (Use group C) according to UL 1059, it supports a rated current of 10 A in both groups. The connector is also compliant with IEC standards, rated for a minimum current of 13.4 A at 20°C. The device maintains operational integrity across temperatures ranging from -50°C to 120°C, ensuring reliable performance in diverse environments.

Additional features include touch-safe protection according to DIN VDE standards, making it suitable for applications requiring enhanced safety measures. The connector is packaged in a box and is designed for secure PCB mounting with a 180° outgoing elbow. Designation Code: Not specified, but the product family belongs to the OMNIMATE Signal series.
