Weidmuller 1443300000

This PCB plug-in connector is designed with a female header and a THT solder connection, ensuring a reliable interface for various applications. With a pin pitch of 5.00 mm and a configuration of 12 poles arranged at a 180° angle, it facilitates efficient signal transmission.

Constructed from Wemid (PA) insulating material and finished in a pebble grey color, this component is rated for a maximum voltage of 300 V under CSA and UL standards, and can handle currents up to 10 A. Its approvals include CSA, EAC, and UR, confirming compliance with safety and quality standards.

Notably, this connector features a solder pin length of 3.2 mm with a tolerance of ± 0.15 mm, ensuring precise alignment during installation. It operates effectively within a temperature range of -50 °C to 100 °C and has a storage temperature range of -25 °C to 55 °C, making it suitable for various environmental conditions.

The connector also adheres to multiple international standards, including IEC 60664-1 and IEC 61984, providing assurance of its performance in demanding applications. Its dimensions are optimized for compact installations, measuring 14.3 mm in height and weighing 9.6 g.
