Weidmuller 1444500000

This PCB plug-in connector features a male header design with a closed side, specifically intended for THT solder connections with a pitch of 5.00 mm. The connector accommodates 18 poles and has a solder pin length of 3.2 mm. The unit is constructed from Wemid (PA) insulating material in a pebble grey color, compliant with various environmental standards including REACH SVHC and RoHS.

With an operating temperature range of -50°C to 100°C, it supports a rated current of 14 A at 20°C for a minimum number of poles. The rated voltage is 500 V for surge voltage class II/2 and 320 V for class III/2, making it suitable for diverse applications. Its design allows for safe finger touch protection according to DIN VDE standards and the connector can be coded for enhanced functionality.

Dimensions include a height of 15 mm and a net weight of 8.28 g. The product family is identified as OMNIMATE Signal - series RSV, and the connector is packaged in a box measuring 46 mm in length, 111 mm in width, and 180 mm in height. The connector complies with IEC standards, specifically IEC 60664-1 and IEC 61984.
