Weidmuller 1869930000

The 3.81 mm printed circuit board terminal is designed for efficient electrical connections with its 6 poles arranged at a 180° angle. The solder pin length measures 1.5 mm, facilitating secure mounting on the PCB. This terminal utilizes a PUSH IN wire connection method, supporting a maximum clamping range of 1.5 mm² for conductor sizes, making it compatible with a variety of wire gauges from AWG 28 to AWG 14.

Constructed from LCP GF insulating material with a black finish, this terminal complies with several international standards, including IEC 60664-1 and IEC 61984, ensuring reliable performance in diverse operating conditions. It operates effectively within a temperature range of -50 °C to 120 °C and has an insulation strength of ≥ 108 Ω, making it suitable for various applications.

In terms of certifications, the terminal is approved by CSA, cURus, EAC, and VDE, ensuring compliance with rigorous safety standards. Its dimensions include a width of 23.25 mm, height of 15.5 mm, and depth of 7.8 mm, with a net weight of 4.739 g. The terminal is packaged in tubes for ease of handling and storage. For further information regarding its operational capabilities, refer to the approval certificate.
