Weidmuller 1870030000

The LSF-SMT 3.81/14/180 1.5SN BK TU is designed for printed circuit board applications, utilizing a PUSH IN connection method. With a pitch of 3.81 mm and a 180° conductor outlet direction, this terminal supports a maximum clamping range of 1.5 mm². The product features a solder pin length of 1.5 mm, ensuring compatibility with various PCB layouts.

Rated for a maximum voltage of 300 V and a rated current of 12 A under UL 1059 standards, the terminal also meets IEC and CSA requirements. The materials used include LCP GF for insulation and copper alloy for contacts, providing durability across a wide operating temperature range from -50 °C to 120 °C. Notably, this terminal exhibits a high Comparative Tracking Index (CTI) of ≥ 175, ensuring reliable performance in challenging environments.

In terms of dimensions, the terminal measures 53.73 mm in width, 15.5 mm in height, and 7.8 mm in depth, with a net weight of 10.06 g. It is packaged in a tube for ease of handling and installation. The product is classified under the OMNIMATE Signal series and adheres to various international standards, ensuring its suitability for a range of industrial applications.
