Weidmuller 1870100000

The terminal, configured for PCB applications, has a pitch of 3.81 mm and accommodates 21 poles. The solder pin length is precisely 1.5 mm, facilitating secure connections. The clamping range supports conductors up to a maximum of 1.5 mm², making it suitable for various wire sizes, specifically from AWG 28 to AWG 14.

Rated for a maximum surge voltage of 320 V under pollution degree II and capable of handling a short-time withstand current of 80 A for 1 second, this terminal ensures reliable performance in demanding scenarios. The material composition includes a black insulating material (LCP GF) with a UL 94 flammability rating of V-0, indicating its suitability for high-temperature environments. Operationally, it can function within an extensive temperature range of -50 °C to 120 °C.

Designed in accordance with IEC standards, it features touch-safe protection (IP 20) and is packaged in a tube for efficient handling. This terminal complies with multiple approvals, including CSA and cURus, confirming its adherence to international safety and quality standards. The product family is categorized under OMNIMATE Signal - series LSF, and it is mounted onto PCBs via THT/THR solder connections.
