Weidmuller 1888990000

The LSF-SMT 7.50/03/135 3.5SN BK RL consists of printed circuit board terminals designed for efficient connectivity. With a pitch of 7.5 mm, this component supports three poles and is equipped with a solder pin length of 3.5 mm. It utilizes a PUSH IN wire connection method, allowing for a maximum clamping range of 1.5 mm².

Rated for a voltage of 300 V and a current of up to 12 A (Use group B), it is suitable for various applications in compliance with UL 1059 and IEC standards. The product is classified under ETIM 6.0 and ETIM 7.0 as EC002643, and has a robust insulation strength of ≥ 108 Ω.

Manufactured with LCP GF insulating material, the terminals exhibit a low flammability rating (UL 94 V-0) and can operate effectively within a temperature range of -50 °C to 120 °C. The design also ensures touch safety according to DIN VDE 0470, classified as IP 20.

This variant's dimensions include a width of 19.2 mm, height of 16.4 mm, and depth of 12.7 mm, while maintaining a lightweight of 4.236 g. The component is packaged in tape for easy handling and installation.
