Weidmuller 1928400000

The PCB plug-in connector, identified by the designation code 7.62HP/03/90FI 3.5SN BK BX, is designed for efficient assembly with a 7.62 mm pitch. It provides a reliable connection through its THT solder connection, featuring a solder pin length of 3.5 mm and a robust construction suitable for various applications.

Rated for a maximum voltage of 600 V and a current of up to 35 A, this connector complies with UL 1059 standards and is suitable for multiple use groups (B, C, D). The connector's clearance distance is a minimum of 6.9 mm, while the creepage distance is at least 9.66 mm, ensuring safe operation in various environments.

Constructed from PA GF insulating material and finished in black (RAL 9011), it has a Comparative Tracking Index (CTI) of ≥ 500 and meets flammability rating UL 94 V-0. With an operational temperature range from -50 °C to 130 °C, it is designed for durability and reliability.

Additional features include safe touch protection as per DIN VDE standards, a volume resistance of 2.00 mΩ, and a maximum plugging force of 7 N per pole. This connector is also coded for easy identification and has a maximum of 25 plugging cycles, highlighting its suitability for repeated use.
