Weidmuller 2014610000

The LUP 12.70/07/90 5.0SN BK BX is a printed circuit board terminal designed for efficient connections in electronic applications. With a pitch of 12.7 mm and a configuration of 7 poles, it utilizes a clamping yoke connection method. The terminal is equipped with solder pins measuring 5 mm in length, ensuring secure attachment to the board.

Rated for a maximum voltage of 600 V and a current of 65 A according to UL 1059 standards, this terminal is suitable for various wire sizes ranging from AWG 22 to AWG 6. It has been tested in accordance with IEC standards, supporting a surge voltage of up to 1,000 V and providing reliable performance under varying environmental conditions with an operating temperature range of -50 °C to 120 °C.

Constructed from Wemid (PA) insulating material in black, the terminal also meets rigorous safety standards, including a Comparative Tracking Index (CTI) of ≥ 600 and a UL 94 flammability rating of V-0. Additionally, it offers touch-safe protection according to DIN VDE standards, making it a reliable choice for PCB applications.

The product is packaged in a box, facilitating secure storage and transportation.
