PS-094-2-WT-S

Specifications

Applications

Wire and Cable Labeling

Brand Name

Brady®

Color

White

Enables Industry Compliance

ASTM D 2671; ASTM E 162; ASTM E 662; ASTM G 155; MIL-STD-202; SAE-AMS-DTL-23053; SAE-AS-81531; UL Recognized

Finish

Matte

For Use with Printer

BBP®72 Label Printer; BRADY IP® Series Label Printer; BradyPrinter i5100; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer

Label/Media Format

Roll

Markers per Roll

500

Primary Noun, Basic Function

Sleeve

Print Technology

Thermal Transfer

Printable Sides

Single-Side Printable

Printer and Label Applications

Wire & Cable

Printer Compatibility

BBP12; BBP11; BBP72; IP300; IP600; PR200Plus; PR300Plus; PR600Plus; i7100

Printer Compatibility (Print)

BBP12; BBP72; i7100

Quantity per Roll

500

Quantity per Row

1

Recommended Ribbon

IP-R6600; R6600

Ribbon Series

R6600

Shape

Rectangle

Shrink Ratio

3:1

Suggested Ribbon Series

R4300; R4502S; R5000; R6600; R6700

Total Qty per Pack

500 Sleeve(s) / Roll

Total Quantity

500

Trade Name

PermaSleeve®

Adhesive (Y/N)

No

Brady Material Number

B-342

Label Properties

Heat Shrink Sleeves

Material

Heat-shrink Polyolefin

Material Properties

Flame-retardant; Heat-shrinkable

Resistance Properties

Chemical-Resistant; Corrosion-Resistant; Humidity-Resistant; Smear-Resistant; UV-Resistant; Weather-Resistant

SAP B-Number

B-342

Core Diameter (mm/cm/m)

76.20 mm

Diameter as Supplied (in/ft/yd)

0.094 in

Diameter as Supplied (mm/cm/m)

2.4 mm

Dimensions

0.182 in H

Dimensions (Metric)

50.80 mm W x 4.60 mm H

Dimensions 2

0.182 in H

Height (in/ft/yd)

0.182 in

Height (mm/cm/m)

4.60 mm

Maximum Service Temperature °C

135 °C

Maximum Service Temperature °F

275 °F

Maximum Wire Diameter (in/ft/yd)

0.08 in

Maximum Wire Diameter (mm/cm/m)

2.03 mm

Maximum Wire Gauge

20 AWG

Minimum Service Temperature °C

-55 °C

Minimum Service Temperature °F

-67 °F

Minimum Wire Diameter (in/ft/yd)

0.023 in

Minimum Wire Diameter (mm/cm/m)

0.58 mm

Minimum Wire Gauge

28 AWG

Recovered Diameter (in/ft/yd)

0.023 in

Recovered Diameter (mm/cm/m)

0.6 mm

Roll Width (in/ft/yd)

2 in

Roll Width (mm/cm/m)

50.8 mm

Size - Width (mm)

50.80 mm

Sleeve Size (in/ft/yd)

0.094 in Dia x 2 in W

Sleeve Size (mm/cm/m)

2.4 mm Dia x 50.8 mm W

Sleeve Width (in/ft/yd)

2 in

Sleeve Width (mm/cm/m)

50.8 mm

Vertical Repeat

0.5 in

Vertical Repeat (mm)

12.70 mm

Web Width (mm/cm/m)

89.00 mm

Wire Diameter Range

0.023 in to 0.08 in

Wire Gauge Range

28 AWG to 20 AWG

Regulatory Information

CA Prop 65 Labeled

Yes

CA Prop 65 Label Warning

WARNING: Cancer - www.P65warnings.ca.gov

Contains CA PROP 65 Substance

Yes Contains-Label required

Contains CA PROP 65 Substance

Yes

Contains CA PROP 65 Warning Type

Cancer

Contains CA Prop 65 Cancer Causing Chemical

Antimony Trioxide

Contains Heavy Metal(s)

No - Does not contain

DOT Regulated Product

No = not regulated by DOT

EU RoHS Compliance

Pass 2011/65/EU(Pass 2015/863)

EU RoHS Compliant

Yes

SDS Safety Data Sheet required

No = MSDS/SDS is not required
