Schneider Electric LC1G115KUEN

This TeSys Giga series contactor delivers robust performance in demanding AC-3 applications requiring currents up to 115A and power ratings of 75kW at 440V. Featuring a wide band, low-consumption 100-250V AC/DC electronic coil, the device ensures efficient operation across varying voltage conditions. An integrated 1NO+1NC auxiliary contact block (rated at 17V 1mA) provides additional functionality and monitoring capabilities. The contactor is engineered for high operational rates, supporting up to 600 cycles per hour in environments with ambient temperatures reaching 60°C. It exhibits exceptional durability, boasting a mechanical lifespan of 5 million cycles. A standard Local Contact Wear Diagnosis (CWD) function continuously monitors the device's health, providing clear indicators via alarm signals. The modular design allows for the replacement of switching modules and enhancement contacts, extending the contactor’s operational life. Installation is facilitated by its ability to be mounted in any quadrant, allowing maintenance without disconnecting cables or busbars. An optional Overload Relay (OLR) can be directly mounted below the contactor. The unit incorporates bolted power connections and spring terminals for control circuits, ensuring ease of installation and rapid replacement. Front face protection meets IP2x standards as defined by IEC 60529 and VDE 0106. It is designed to operate in ambient air temperatures ranging from -25°C to 60°C, with no derating required...
