The S201M-B13 is a miniature circuit breaker designed for reliable overload and short circuit protection. It features a B tripping characteristic and is rated for operational voltages of 230/400 V AC, with a maximum breaking capacity of 10 kA.This device complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards, making it suitable for various applications. It supports a wide range of configurations, including 1P, and has a compact design with a width of 17.5 mm, allowing for efficient use of space on DIN rail mounts TH35-15 and TH35-7.5.With an operational temperature range of -25 to +55 °C and a dielectric test voltage of 2 kV, this circuit breaker is designed for durability in diverse environmental conditions. The product also incorporates features for enhanced sustainability, achieving a recyclability rate of 80.7% in compliance with EN45555.

The Miniature Circuit Breaker with a rating of 50 A adheres to the standards set by IEC/EN 60898-1 and IEC/EN 60947-2, making it suitable for residential, commercial, and industrial uses. It features a delayed thermal mechanism for overload protection and an electromechanical mechanism for short circuit protection. This model is designed for a maximum operational voltage of 440 V AC and boasts a breaking capacity of up to 6 kA at 400 V AC.With a compact design, the device occupies a width of 70 mm and is mountable on standard DIN rails (TH35-15 and TH35-7.5), allowing for versatile installation options. The product has a mechanical endurance of 20,000 cycles and an electrical endurance of 10,000 AC cycles, ensuring reliability and longevity in operation.Environmental considerations are met with a recyclability rate of 80.7% and adherence to sustainability initiatives, including take-back services for recycling. Additionally, it is classified under ETIM 9: EC000042 for miniature circuit breakers.

The S204-K32 miniature circuit breaker is designed for current limiting applications and features two distinct tripping mechanisms: a delayed thermal mechanism for overload protection and an electromechanical mechanism for short circuit protection. It is compliant with standards such as IEC/EN 60898-1, IEC/EN 60947-2, and UL1077, ensuring its suitability for residential, commercial, and industrial environments.This model supports a rated operational voltage of up to 440 V AC and a rated current of 32 A, with a breaking capacity of 6 kA at 400 V AC. The dimensions of the breaker are 70 mm in width, 88 mm in height, and 69 mm in depth, with a net weight of 0.48 kg. The device features a toggle actuator type and can be mounted on DIN rails according to IEC 60715.In terms of environmental impact, the S204-K32 adheres to ABB EcoSolutions with a recyclability rate of 80.7% and does not contribute to landfill waste. It can operate in ambient temperatures ranging from -25 to +55 °C and is rated with a degree of protection IP20.

The S201M-C50 is a miniature circuit breaker designed with a capacity of 50 A and a tripping characteristic of C, making it suitable for overload and short circuit protection. The device adheres to IEC/EN 60898-1 and IEC/EN 60947-2 standards, ensuring its reliability in residential, commercial, and industrial environments. With a breaking capacity of up to 10 kA at 230/400 V AC, this circuit breaker is equipped with both delayed thermal tripping and electromechanical mechanisms. Its compact design allows for mounting on standard DIN rails (TH35-15 and TH35-7.5), occupying just 17.5 mm of modular space. Additionally, it can operate in ambient temperatures ranging from -25 °C to +55 °C, while providing a degree of protection rated at IP20 without cover and IP40 with cover. The S201M-C50 is engineered for durability, featuring an electrical endurance of 10,000 AC cycles and a mechanical endurance of 20,000 cycles.

The S201M-C0.5 Miniature Circuit Breaker features a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection. This model is designed for installation on DIN rail TH35-15 or TH35-7.5 according to IEC 60715, allowing for versatile mounting positions. Its compact dimensions include a width of 17.5 mm and a height of 88 mm, while maintaining a weight of 0.125 kg. The device operates effectively within a temperature range of -25 to +55 °C and complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards, making it suitable for residential, commercial, and industrial applications. The S201M circuit breaker is equipped with a C tripping characteristic and can handle rated short-circuit capacities of up to 10 kA at 230/400 V AC. It also provides contact position indication through red and green indicators. Its design includes features that facilitate easy installation and maintenance, such as screw terminals with a tightening torque of 2.8 N·m. Additionally, the breaker supports a high degree of environmental sustainability with a recyclability rate of 80.7% and compliance with RoHS and REACH directives. The product is designed to minimize waste and enhance longevity, aligning with modern environmental standards.

The S201M-C63 miniature circuit breaker is engineered for efficient current limiting and operational reliability. It incorporates two distinct tripping mechanisms: a delayed thermal mechanism for overload protection, and an electromechanical mechanism for short circuit protection. This model supports a rated operational voltage of 230/400 V AC, with a rated short-circuit capacity of 10 kA, making it suitable for a range of applications.With a compact design, the S201M-C63 measures 17.5 mm in width and 88 mm in height, allowing for installation on standard DIN rails (TH35-15 or TH35-7.5) in any position. The product conforms to IEC/EN 60898-1 and IEC/EN 60947-2 standards, ensuring compliance for various installation environments.Additionally, the device features a robust casing made of insulation material compliant with Group II standards, providing an ambient operational temperature range from -25 °C to +55 °C. The degree of protection is rated IP20, and with the optional cover, it can reach IP40 for enhanced safety. The S201M-C63 also offers a high mechanical endurance of 20,000 cycles and an electrical endurance of 10,000 AC cycles, ensuring longevity and reliability.This product is part of the S200M range, which includes various characteristics and configurations to meet specific operational needs. The bottom-fitting auxiliary contact feature allows for space-saving installations.

ABB's S200M compact miniature circuit breakers are designed to provide reliable protection against overloads and short circuits. They feature a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short circuit protection. These MCBs are available in various characteristics (B, C, D, K, Z), configurations (1P, 2P, 3P, 4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All models comply with IEC/EN 60898-1 and IEC/EN 60947-2, making them suitable for residential, commercial, and industrial applications. The bottom-fitting auxiliary contact can be mounted on S200M to save space by 50%.

System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.

The RD3 series of electronic residual current relays provides residual current protection and monitoring functions. This device can be used in conjunction with all MCBs of S200 series and Tmax range moulded case devices up to T5, for industrial installations.

The RD2 Residual Current Monitor is designed for use in AC current systems, operating within a voltage range of 230 to 400 V AC. It utilizes an external transformer to accurately detect leakage currents. The device allows for sensitivity and intervention time adjustments via minidip settings, with a maximum delay-on energization time of 5 seconds and a minimum adjustable delay of 0.3 seconds.With a compact design measuring 35 mm in width, 85 mm in height, and 65 mm in depth, the monitor weighs 0.105 kg and is suitable for DIN-Rail mounting. It complies with IEC EN 62020 standards and features a Type A residual current classification, capable of responding to amperage levels up to 2000 mA.This monitor is classified under ETIM 9 as EC001445, indicating its role in residual current monitoring relay applications. It adheres to RoHS regulations as per EU Directive 2011/65/EU, ensuring material compliance. The product is packaged as a single unit in a box, with a gross weight of 0.15 kg. Its technical specifications make it suitable for various industrial applications, ensuring reliable operation in monitoring leakage currents.

The F202 A-40/0.03 Residual Current Circuit Breaker 2P A type 30 mA from ABB is designed to provide exceptional protection for people and installations against fault currents to earth. This RCCB is part of the F200 series, known for its comprehensive range of standard instantaneous and selective AC and A types, as well as configurations for special applications.Key Features:Compliance with IEC/EN 61008 and UL 1053 standardsRated voltage of 230 V and rated current of 40 AHigh electrical endurance with up to 10,000 cyclesMounting type: DIN-RailEnvironmental Product Declaration (EPD) availableApplications:The F202 A-40/0.03 RCCB is ideal for residential, commercial, and industrial installations where protection against earth fault currents is crucial. Its robust design and high reliability make it suitable for various applications, ensuring safety and compliance with international standards.

The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.

The F202 A-100/0.3 Residual Current Circuit Breaker is designed to protect both personnel and electrical installations from earth fault currents. With a rated operational voltage of 230 V and an insulation voltage of 500 V, it meets the standards IEC/EN 61008 and UL 1053.This device is equipped with two poles and operates on an instantaneous characteristic. Its compact dimensions include a width of 35 mm and a depth of 69 mm, allowing for efficient installation on DIN rails in various positions. The circuit breaker has a mechanical endurance of up to 20,000 cycles and an electrical endurance of 10,000 cycles, ensuring reliable long-term performance.Operating within an ambient temperature range of -25 to 55 °C, it is suitable for diverse environments. The device's degree of protection is rated at IP2X for terminals and IP40 for the housing, providing adequate safety against dust and contact. The F202 series offers configurations for standard and specialized applications, addressing a wide variety of installation requirements.

ABB's F200 series of RCCBs is a comprehensive solution that ensures safety by protecting against fault currents to earth. This range includes a wide variety of configurations, catering to standard applications as well as special ones. The series is known for its instantaneous and selective AC and A types, making it a versatile choice for diverse installations.

The F202 A-63/0.3 residual current circuit breaker is engineered to safeguard both personnel and installations from fault currents directed to earth. This model is part of the F200 series, which includes various configurations suitable for standard instantaneous and selective applications. It features a two-pole design with a rated current of 63 A and a rated residual current of 300 mA.Compliant with IEC/EN 61008 and UL 1053 standards, this device operates under a voltage rating of 230 V and offers a rated insulation voltage of 500 V. With a maximum impulse withstand voltage of 4 kV and a conditional short-circuit current rating of 10 kA, the breaker ensures reliable operation in demanding environments. The device is suitable for mounting on DIN rails in any position, with dimensions of 35 mm in width, 85 mm in height, and a depth of 69 mm.Environmental considerations are paramount, as the product operates effectively within an ambient temperature range of -25 to 55 °C and is classified with a pollution degree of 2. Additionally, the device is designed to withstand vibrations and shocks as outlined in IEC 60068-2-6 and IEC 60068-2-27, ensuring durability in various conditions. The F202 A-63/0.3 also supports a diverse range of connection types, with a tightening torque of 2.8 N·m and options for auxiliary contacts and other accessories.

The ABB F204 series of Residual Current Circuit Breakers (RCCBs) is designed to safeguard individuals and installations from fault current to earth. The series offers a comprehensive range of configurations, including standard instantaneous and selective AC and A types, as well as some options for special applications. Key Features: Protection against fault current to earth Wide range of configurations for various applications

The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.

The F204 A-25/0.03 Residual Current Circuit Breaker 4P A type 30 mA from ABB is designed to provide maximum protection for people and installations against fault currents to earth. This device is part of the F200 series, known for its reliability and efficiency in safeguarding electrical systems. The series offers a wide range of standard instantaneous and selective AC and A types, ensuring comprehensive protection for various applications.Key Features:Instantaneous and selective AC and A typesHigh reliability in fault current protectionSuitable for various special applicationsThe F204 A-25/0.03 RCCB is ideal for ensuring safety in residential, commercial, and industrial environments. Its robust design and advanced technology make it a trusted choice for electrical protection.

The F204 A-100/0.03 is designed to safeguard individuals and installations from fault currents to earth. It is part of the F200 series, which features a variety of standard instantaneous and selective AC and A types, along with configurations suitable for specific applications.Operating with a rated voltage of 230/400 V and a rated current of 100 A, this device is compliant with standards IEC/EN 61008 and UL 1053. The RCCB ensures reliable performance, including a rated impulse withstand voltage of 4 kV and a conditional short-circuit current of 10 kA.Featuring a compact design that occupies 4 modular spacings, it measures 70 mm in width, 85 mm in height, and 69 mm in depth. The device can be mounted on DIN rail and operates effectively within an ambient temperature range of -25 to 55 °C.Additional specifications include a mechanical endurance of 20,000 cycles and an electrical endurance of 10,000 cycles. Its degree of protection is rated at IP2X for terminals and IP40 for the housing. The product is designed with screw terminals and supports various connecting capacities for busbars, rigid, and flexible conductors.The F204 A-100/0.03 meets environmental standards, including RoHS compliance and a carbon footprint of 17.16 kg CO₂ eq.

The ABB F200 series of RCCBs ensures safety by protecting individuals and installations from fault currents to earth. This comprehensive range includes standard instantaneous and selective AC and A types, along with configurations tailored for specific applications.
