9999SX11

Environment

Product Certifications

UL Listed || CSA || UL Recognized

Contractual warranty

Warranty

18 months

Offer Sustainability

China Rohs Regulation

Product out of China RoHS scope. Substance declaration for your information.

Eu Rohs Directive

Not compliant

Reach Regulation

Reference contains Substances of Very High Concern above the threshold

California Proposition 65

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Complementary

[Ue] Rated Operational Voltage

<= 600 V AC 50/60 Hz

Auxiliary Contact Composition

1 NO

Nema Size

00 || 0 || 2 || 1

Rated Breaking Capacity

3 A 120 V AC inductive control circuit UL 508 || 1.5 A 240 V AC inductive control circuit UL 508 || 0.75 A 480 V AC inductive control circuit UL 508 || 0.6 A 600 V AC inductive control circuit UL 508 || 5 A <= 600 V AC resistive control circuit UL 508

Specifications

Range Of Product

type S

Product Or Component Type

Auxiliary Contact Module

Product Destination

contactor || starter
