ABB 2CDS271001R0577

The S201M-K50 miniature circuit breaker features a two-mechanism tripping design, incorporating a delayed thermal feature for overload protection and an electromechanical mechanism for short circuit protection. With a rated current of 50 A and a breaking capacity of up to 10 kA at 230/400 V AC, this product is suitable for various applications, including residential, commercial, and industrial settings.

Compliant with IEC/EN 60898-1 and IEC/EN 60947-2 standards, the device is available in a single pole configuration. The compact dimensions of 17.5 mm in width, 88 mm in height, and 69 mm in depth facilitate installation on DIN rails TH35-15 and TH35-7.5. Furthermore, the device supports a wide operational voltage range of up to 253 V AC and 72 V DC, ensuring versatility in various electrical systems.

The S201M-K50 also incorporates an energy limiting class of 3, indicating its effectiveness in limiting energy during fault conditions. With a mechanical endurance rated for 20,000 cycles, this circuit breaker is designed for durability and reliability.
