Mersen MPDB69150

The Power Distribution Block (PDB) is engineered to facilitate the safe distribution of electrical power, efficiently splicing cables and creating secondary circuits from a primary source. This model features a notable maximum operating temperature of 80 °C and is compliant with UL508A and the National Electrical Code®.

Constructed from durable materials, the block allows for a variety of configurations with options for single or dual conductor inputs, accommodating up to 30 secondary outputs. It is rated for 1000V AC and DC, supporting numerous applications in both industrial and commercial settings.

The design incorporates adder poles, which can be effortlessly stacked to create multi-pole units in the field without tools, enhancing installation flexibility. The insulators are made from glass-filled polycarbonate, ensuring strength and resistance to breakage. Optional hinged safety covers provide additional protection where necessary.

With a torque rating of 350-#6 for primary connections and #4-#14 for secondary, this PDB accommodates a range of wire sizes. Its flame rating of 94 V-0 further ensures safety in operation. The MPDB series, including this model, is available in aluminum and copper variants, tailored for various electrical configurations.
