Phoenix Contact 1681101

The SACC-M12MR-4CON-PG7-M is an angled plug connector designed for universal applications. It features a 4-position configuration with A-coding, facilitating reliable connections in various environments. The connector is equipped with a Pg7 screw connection for secure cable attachment, accommodating external cable diameters ranging from 4 mm to 6 mm.

Constructed with a knurl made of zinc die-cast and nickel-plated for durability, this connector exhibits an overvoltage category of II and is rated for a pollution degree of 3. Its compact dimensions include a housing diameter of 20 mm and a length of 41 mm, making it suitable for tight spaces.

With a rated nominal voltage of 250 V AC and a nominal current of 4 A, this connector is engineered to endure harsh conditions, supporting an ambient temperature range from -40 °C to 85 °C. The degree of protection IP67 ensures that it is impervious to dust and can withstand temporary immersion in water.

This product complies with IEC 61076-2-101 standards, ensuring compatibility and reliability in industrial applications. Its sturdy construction features materials such as NBR for sealing and CuZn for contacts, which contribute to a contact resistance of ≤ 8 mΩ and an insulation resistance of ≥ 100 MΩ.
