Schneider Electric
170ADO54050
discrete output module Modicon Momentum - 16 O solid state
- Erhalten Sie bis zu 90 Tage Zahlungsziele von 500+ Lieferanten
- Wiederverkaufsrabatte bis zu 40%!
€234.00
1
Zahlungsmöglichkeiten:
Insgesamt 18 Parts In-Stock von 16 Distributors
Produktbedingungen:
Angebot mit Herstellervorlaufzeit
Lieferung:1 - 2 Viele Arbeitstage
Bester Preis:
€259.99
Additional Information
- Part Number
- 170ADO54050
- UNSPSC
- 32151601
- Tariff Code
- 8538908160
- Country of Origin
- ID
Environment
- Product Certifications
- CSA || UL || FM Class 1 Division 2
- Ambient Air Temperature For Operation
- 0-60 °C
- Resistance To Electromagnetic Fields
- 10 V/m 80...1000 MHz IEC 801-3
- Ambient Air Temperature For Storage
- -40-85 °C
- Relative Humidity
- 95-95 % without condensation
- Resistance To Electrostatic Discharge
- 4 kV contact IEC 801-2 || 8 kV on air IEC 801-2
- Operating Altitude
- <= 16404.2 ft (5000 m)
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Mercury Free
- Yes
- Environmental Disclosure
- ENVPEP1403005EN
- Sustainable Offer Status
- Green Premium product
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Weee
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation
- X
- Circularity Profile
- ENVEOLI1403005EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
Complementary
- Power Dissipation
- 7.5 W maximum || 6 W typical
- Height
- 141.5 mm
- Minimum Output Current
- 30 mA
- [Ue] Rated Operational Voltage
- 120 V AC
- Terminals Description Plc N°1
- (3)OUT_DIS#3 || (4)OUT_DIS#4 || (12)OUT_DIS#12 || (8)OUT_DIS#8 || TB || (10)OUT_DIS#10 || (1N)PW || (1)OUT_DIS#1 || (9)OUT_DIS#9 || (1L+)PW || (5)OUT_DIS#5 || (13)OUT_DIS#13 || (15)OUT_DIS#15 || (2)OUT_DIS#2 || (11)OUT_DIS#11 || (6)OUT_DIS#6 || (7)OUT_DIS#7 || (14)OUT_DIS#14 || (16)OUT_DIS#16
- Maximum Voltage Drop
- <1.5 V 0.5 A at state 1
- Response Time
- 1/2 x 1/f (= 0.5 of one line cycle) from state 0 to state 1 || 1/2 x 1/f (= 0.5 of one line cycle) from state 1 to state 0
- Current Consumption
- 125 mA 120 V AC
- Surge Current
- 10 A for 2 cycles || 15 A for 1 cycle || 5 A for 3 cycles
- Marking
- CE
- Discrete Output Current
- 4 A per group || 8 A per module
- Net Weight
- 0.284 kg
- Maximum Leakage Current
- 1.9 mA 120 V AC
- Local Signalling
- for channel status 16 LEDs
- Output Overload Protection
- internal fuse
- Width
- 125 mm
- Depth
- 47.5 mm
- Isolation Between Channels And Bus
- 1780 V AC for 1 minute
Specifications
- Discrete Output Type
- triac
- Group Of Channels
- 2 groups of 8 outputs
- Range Of Product
- Modicon Momentum automation platform
- Current Per Channel
- 0.5 A
- Product Or Component Type
- discrete output base AC
- Discrete Output Voltage
- 120 V AC
- Discrete Output Number
- 16
- Short-Circuit Protection
- internal fuse, 5 A slow-blow per group
- Protective Treatment
- TC
