- Prospective Line Isc
- 22 kA
- Network Frequency
- 50-60 Hz
- Power Dissipation In W
- fan 229.0 W 380 V 4 kHz
- Line Current
- 26.5 A 380 V heavy duty) || 18.7 A 500 V heavy duty)
- Analogue Output Type
- software-configurable current AQ1 0...20 mA 800 Ohm 10 bits || software-configurable voltage AQ1 0...10 V DC 470 Ohm 10 bits
- Discrete Output Type
- open collector DQ+ 0-1 kHz 30 V DC 100 mA || open collector DQ- 0-1 kHz 30 V DC 100 mA
- Asynchronous Motor Control Profile
- voltage/frequency ratio, 5 points || flux vector control without sensor, standard || voltage/frequency ratio - Energy Saving, quadratic U/f || flux vector control without sensor - Energy Saving || voltage/frequency ratio, 2 points
- Maximum Switching Current
- relay output R1A, R1B, R1C resistive, cos phi = 1 3 A 250 V AC || relay output R1A, R1B, R1C resistive, cos phi = 1 3 A 30 V DC || relay output R1A, R1B, R1C, R2A, R2C inductive, cos phi = 0.4 7 ms 2 A 250 V AC || relay output R1A, R1B, R1C, R2A, R2C inductive, cos phi = 0.4 7 ms 2 A 30 V DC || relay output R2A, R2C resistive, cos phi = 1 5 A 250 V AC || relay output R2A, R2C resistive, cos phi = 1 5 A 30 V DC
- 4 Quadrant Operation Possible
- true
- Relative Symmetric Network Frequency Tolerance
- 5 %
- Apparent Power
- 16.2 kVA 500 V heavy duty)
- Net Weight
- 3.6 kg
- Relay Output Type
- configurable relay logic R1A 1 NO 100000 cycles || configurable relay logic R1B 1 NC 100000 cycles || configurable relay logic R1C || configurable relay logic R2A 1 NO 100000 cycles || configurable relay logic R2C
- Switching Frequency
- 2...16 kHz adjustable || 4...16 kHz with derating factor
- Analogue Input Number
- 3
- Motor Slip Compensation
- automatic whatever the load || adjustable 0...300 % || not available in voltage/frequency ratio (2 or 5 points)
- Discrete Output Number
- 3
- Method Of Access
- slave CANopen
- Discrete Input Number
- 7
- With Safety Function Safe Stop 1 (Ss1)
- true
- Width
- 150 mm
- Depth
- 178.0 mm
- Analogue Input Type
- AI1 voltage 0...10 V DC 30 kOhm 10 bits || AI2 bipolar differential voltage +/- 10 V DC 30 kOhm 10 bits || AI3 current 0...20 mA (or 4-20 mA, x-20 mA, 20-x mA or other patterns by configuration) 250 Ohm 10 bits
- Maximum Output Frequency
- 0.599 kHz
- Height
- 232.0 mm
- Acceleration And Deceleration Ramps
- linear || U || S || CUS || ramp switching || acceleration/deceleration ramp adaptation || acceleration/deceleration automatic stop with DC injection
- Maximum Output Voltage
- 500 V
- Base Load Current At High Overload
- 17.0 A
- Transient Overtorque
- 170-200 % of nominal motor torque
- With Safety Function Safe Torque Off (Sto)
- true
- Analogue Output Number
- 1
- Minimum Switching Current
- relay output R1A, R1B, R1C, R2A, R2C 5 mA 24 V DC
- Discrete Input Logic
- positive logic (source) || negative logic (sink)
- Brake Chopper Integrated
- true
- Nominal Switching Frequency
- 4 kHz
- Braking To Standstill
- by DC injection
- Discrete Input Type
- STO safe torque off, 24 V DC1.5 kOhm || DI1...DI6 logic inputs, 24 V DC 30 V) || DI5 programmable as pulse input 0-30 kHz, 24 V DC 30 V)
- Protection Type
- input phase breaks drive || overcurrent between output phases and earth drive || overheating protection drive || short-circuit between motor phases drive || thermal protection drive
- With Safety Function Safely Limited Speed (Sls)
- true
- Synchronous Motor Control Profile
- vector control without sensor
