Siemens 5SV4342-0

The residual current circuit breaker operates with a 4-pole configuration and is classified as Type AC. It is designed to handle a rated current of 25 A and a fault current of 30 mA, making it suitable for various applications where current leakage protection is essential. This device features a rated operational voltage of 400 V and is compliant with national installation standards.

With a mechanical service life of approximately 10,000 operating cycles, this circuit breaker is rated for a short-circuit current of up to 10 kA. The dimensions include a depth of 70 mm and a width of 72 mm, allowing for standard DIN rail mounting. It supports conductor cross-sections ranging from 0.75 mm² to 35 mm² and can be installed in various positions.

Furthermore, it has a degree of protection IP20 and is suitable for ambient temperatures between -25 °C and 45 °C. The device also incorporates an interlocking mechanism and is designed to accommodate additional equipment. It is important to note that the usage of this device may be subject to specific regulations in different countries.
