Wago
2007-8873
1 / 3
- Part Number
- 2007-8873
- Tariff Code
- 85369010000
- UPC
- 4050821776697
- ETIM
- Group Code : EG000017
- Group Description : Low-voltage Industrial Components
- Class Description : Distribution terminal block
- Class Code : EC000276
- Version : 7
€71.30
netVersand von:
€35.00
1
Zahlungsmethoden:
- Bestes Angebot von:
Vertrauenswürdiger Automa.Net Lieferant- Verfügbarkeit:
- 30 Stk.Auf LagerAktualisiert am: 20-11-2024
- Garantie:
- 12 Monate
- Geschätzte Lieferung:
- 26-27 November zu Vereinigtes Königreich
- Zustand:
- Neu versiegelt ab Werk
Neu versiegelt ab Werk - Ein brandneuer, unbenutzter, ungeöffneter, unbeschädigter Artikel in seiner original vom Hersteller versiegelten Verpackung.
Sicherer Zahlungsprozess
Rückgabe- und Erstattungsrichtlinien
Versandrichtlinien
Garantiebedingungen
Ratings Per Iec/En
- Nominal voltage (III/3)
- 500 V
- Rated impulse voltage (III/3)
- 6 kV
- Legend (ratings)
- (III / 3) ≙ Overvoltage category III / Pollution degree 3
Environmental Requirements
- Processing temperature
- -35 … +85 °C
- Continuous operating temperature
- -60 … +105 °C
Physical Data
- Width
- 112 mm / 4.409 inches
- Height
- 99.6 mm / 3.921 inches
- Depth from upper-edge of DIN-rail
- 65.3 mm / 2.571 inches
- Module width
- 8 mm / 0.315 inches
Material Data
- Note (material data)
- <a href="https://www.wago.com/us/material-specifications" href="_blank">Information on material specifications can be found here</a>
- Color
- Multicoloured
- Material group
- I
- Insulation material
- Polyamide (PA66)
- Flammability class per UL94
- V0
- Fire load
- 5.527 MJ
- Weight
- 347.501 g
Mechanical Data
- Mounting type
- DIN-35 rail
- Marking level
- Center/side marking
Specifications
- Product Group Code
- 0022
Commercial Data
- Packaging type
- Box
- Country of origin
- DE
- GTIN
- 4050821776697
- Customs tariff number
- 85369010000
Connection 1
- Connection technology
- Push-in CAGE CLAMP®
- Actuation type
- Operating tool
- Connectable conductor materials
- Copper
- Nominal cross-section
- 6 mm² / 10 AWG
- Solid conductor
- 0.5 … 10 mm² / 20 … 8 AWG
- Solid conductor; push-in termination
- 1 … 10 mm² / 14 … 8 AWG
- Fine-stranded conductor
- 0.5 … 10 mm² / 20 … 8 AWG
- Fine-stranded conductor; with insulated ferrule
- 0.5 … 6 mm² / 20 … 10 AWG
- Fine-stranded conductor; with uninsulated ferrule
- 1.5 … 6 mm² / 16 … 10 AWG
- Fine-stranded conductor; with ferrule; push-in termination
- 2.5 … 6 mm² / 16 … 10 AWG
- Strip length
- 13 … 15 mm / 0.51 … 0.59 inches
- Wiring direction
- Front-entry wiring
