Wago

706-100/1602-200

1 / 3
thumbnail
thumbnail
thumbnail
Part Number
706-100/1602-200
Tariff Code
85444290900
UPC
4050821452447
ETIM
Group Code : EG000026
Group Description : Sensors
Class Description : Sensor-actuator patch cord
Class Code : EC001855
Version : 7
  • Erhalten Sie bis zu 90 Tage Zahlungsziele von 500+ Lieferanten
  • Wiederverkaufsrabatte bis zu 40%!
Sign-Up
Preisanfrage senden
1
Zahlungsmöglichkeiten:
Fordern Sie ein Angebot an und wir senden Ihnen Informationen zu Verfügbarkeit und Preis.

Environmental Requirements

Ambient temperature (operation)
-20 … +50 °C

Electrical Data

Operating voltage
≤ AC/DC 35 V
Current per wire (max.)
1 A

Physical Data

Cable length
2 m

Material Data

Fire load
0.000 MJ
Weight
202.000 g

Connection 2

Connector 2
Open-ended
Connection type 2
Open-ended

Specifications

Product Group Code
0030

Commercial Data

Packaging type
Box
Country of origin
FR
GTIN
4050821452447
Customs tariff number
85444290900

Notes

Note
When using more than 10 wires, the maximum current per wire must be reduced to 0.7 A.

Connection 1

Connector
Pluggable connector per DIN 41651; female connector
Pole number 1
16
Connection type 1
System
Wire cross-section
0.14 mm²
Connection type
Pluggable Connector per DIN 41651
