Weidmuller 1885030000

The LSF-SMT 5.08/03/135 3.5SN BK TU is designed for printed circuit boards, with a pitch of 5.08 mm and a 135° conductor outlet direction. This terminal accommodates a maximum clamping range of 1.5 mm² and is suitable for a variety of wire connections using a PUSH IN method.

It operates at a rated voltage of 300 V and supports a maximum current of 12 A, adhering to UL 1059 standards. The device has been tested according to IEC standards, ensuring reliable performance with a rated impulse voltage of 4 kV under pollution degree II/2.

Constructed from LCP GF insulating material, the terminal exhibits a flammability rating of V-0 and is designed for optimal durability, functioning within an operating temperature range of -50 °C to 120 °C. With a compact size of 14.36 mm in width and a net weight of 3.368 g, it is packaged in a tube for efficient handling.

This terminal is compliant with various industry standards including CSA, cURus, EAC, and VDE, ensuring broad applicability in industrial settings.
