Weidmuller 1885720000

The LSF-SMT 3.50/09/135 3.5SN BK TU is designed for printed circuit boards, featuring a 3.50 mm pitch and accommodating 9 poles. The solder pin measures 3.5 mm in length, allowing for reliable connections. With a maximum clamping range of 1.5 mm², this terminal utilizes a PUSH IN wire connection method.

This component adheres to multiple standards, including UL 1059 and IEC, ensuring reliability with a rated voltage of 300 V and a rated current of 12 A under specific conditions. The terminal is constructed using LCP GF insulating material and is colored black, with operational elements made of white PPA GF.

Dimensions include a width of 32.2 mm, height of 16.4 mm, and depth of 12.7 mm, with a net weight of 7.76 g. It operates within a temperature range of -50 °C to 120 °C, with a moisture sensitivity level of 1. The product is packaged in tubes for ease of handling.

Additional specifications include a touch-safe design according to DIN VDE standards and a volume resistance of 1.60 mΩ. The component complies with various certifications such as CSA, cURus, EAC, and VDE, confirming its suitability for diverse industrial applications. The product family is categorized under OMNIMATE Signal.
