Weidmuller 1906950500

This M12 Connector Cable, designated as SAIL-M12BW-3S5.0U, is designed for sensor and actuator applications. The cable has an angled socket and is equipped with three poles, suitable for a variety of industrial connections. The robust construction includes a PUR sheath, ensuring durability and flexibility within temperature ranges of -25°C to +80°C for both moving and stationary conditions.

With a rated voltage of 250 V and a current rating of 4 A, this cable meets stringent standards including IEC 61076-2-101. The contact surfaces are gold-plated, enhancing conductivity and reliability in demanding environments. The assembly is shielded to minimize interference and features a protection degree of IP65, IP66, IP67, and IP68 when properly connected.

In terms of mechanical durability, the cable supports at least 100 plugging cycles, while the bending radius specifications ensure it can withstand the rigors of movement and installation. The outer diameter is maintained at 5 ± 0.2 mm, with a core cross-section of 0.34 mm². Additionally, this product is compliant with various approvals, including cULus and RoHS, ensuring adherence to global safety and environmental standards.
