Weidmuller 1925391000

The M12 Connector Cable SAIL-M12WM12W-4-10V features a robust design with a total length of 10 meters, accommodating 4 poles for effective electrical connectivity. This cable utilizes an M12 / M12 connection thread, ensuring secure and reliable connections. The cable's housing is constructed from PVC, providing adequate protection while being halogen-free.

With an operational temperature range of -25°C to +80°C, it supports diverse applications in various environments. The cable is rated for a maximum voltage of 250 V and a current of 4 A, making it suitable for a range of industrial automation uses. The contact surfaces are gold-plated, enhancing conductivity and durability.

In terms of protection, it meets the standards of IP65, IP66, IP67, and IP68 when properly installed, ensuring it is well-suited for challenging conditions. Furthermore, the cable has undergone rigorous testing and is compliant with numerous standards, including IEC 61076-2-101, and has certifications such as cULus (File Number: E307231).
