Weidmuller 1926690500

This M12 sensor/actuator line offers a straight pin configuration with five poles and measures 5 meters in length. The connection type adheres to IEC 61076-2-101 standards and possesses a protection degree of IP65, IP66, IP67, and IP68 when properly secured. The housing is constructed from PUR with a diecast zinc threaded ring, ensuring durability under various environmental conditions.

The cable, shielded for enhanced performance, has a core cross-section of 0.34 mm² and an outer diameter of 5.7 ± 0.2 mm. It operates efficiently within a temperature range of -25 to +80 °C for both stationary and moving applications. This product features a rated voltage of 125 V and a rated current of 4 A, with a gold-plated contact surface that enhances conductivity.

Additionally, it is designed for up to 100 plugging cycles and is compliant with various environmental standards, including REACH. For applications requiring flexibility, the cable is suitable for cable carriers and demonstrates resistance to hydrolysis and microbial growth.

Notably, the product is classified under the Designation Code and complies with UL approvals.
