Balluff BMF 103K-PS-C-2A-SA2-S49-00,3

The magnetic field sensors for T-slots provide an effective solution for detecting piston positions without direct contact, facilitating operation through cylinder walls. These sensors can be directly mounted into the slot, ensuring a firm grip while allowing for flush installation in space-constrained environments. They are compatible with cylinders and grippers utilizing both strong and weak magnets and are equipped with bright LEDs for clear indication.

With dimensions of 9 x 4.8 x 16 mm, these sensors feature a connection type of M8x1-Male, 3-pin, and come with a 0.3 m PUR cable. The sensors are optimized for short-stroke cylinders, operating efficiently with a switching frequency of 30,000 Hz and a voltage range of 10-30 VDC. The robust PBT housing ensures durability, even in challenging environments with an ambient temperature range of -25 to 85 °C and an IP67 rating for protection against dust and water intrusion. Compliance with cULus, CE, and WEEE standards further validates their reliability.
