Schneider Electric LC1K0601F7

The LC1K0601F7 is a compact 3-pole contactor from the TeSys K range, designed specifically for motor control applications. It operates at a rated current of 6A in AC-3 utilization category with a maximum motor power of 2.2kW at 400V. The device is equipped with a 110V 50/60Hz AC coil and includes one normally closed (1 NC) auxiliary contact.

This unit is compatible with DIN-rail mounting and features screw clamp terminals for secure electrical connections. With a width of only 45mm, it is suitable for installations where space is limited. It is certified to multiple standards including IEC, UL, and CSA, ensuring compliance with industry requirements.

The contactor is optimized for standard power applications and can be complemented with auxiliary contact blocks and thermal relays. It offers a control circuit that functions effectively with both 50Hz and 60Hz power supplies. The unit's environmental robustness is reflected in its IP2X degree of protection and a wide operational temperature range, from -50°C to 80°C for storage.

In terms of durability, the LC1K0601F7 is rated for 10 million mechanical cycles and 1.3 million electrical cycles at 6A AC-3. The design includes features for minimizing electrical and mechanical stress, making it suitable for various industrial applications.
