Schneider Electric LC1K0610Q7

The TeSys K contactor features three poles (3NO) suitable for motor control tasks, supporting operational currents up to 6A at 690V AC-3, and up to 20A for non-inductive loads at the same voltage category. It operates with a coil voltage of 380/400V at 50/60Hz and is equipped with one built-in auxiliary contact. The device is designed for a maximum operating rate of 600 cycles per hour and can function effectively in environments up to 50°C, ensuring reliability for standard applications.

Measuring just 45mm in width, it allows for versatile installation options such as DIN-rail mounting or direct screw fixation. The contactor is rated for ambient air temperatures during storage ranging from -50°C to 80°C, and is compliant with multiple international standards including IEC, UL, CSA, CCC, and EAC, which enhances its applicability across various industrial settings.

With an IP2X degree of protection, the contactor is built to withstand mechanical shocks and vibrations, adhering to IEC standards for robustness. This product is designed to meet environmental regulations, being mercury-free and compliant with RoHS directives, thus contributing to sustainable industrial practices. For detailed specifications, refer to the product's technical documentation.
