Schneider Electric LC2K0610F7

The product is a 3-pole reversing contactor with a rated operational current of 6 A, suitable for motor control applications. It operates within a voltage range of up to 690 V AC in the AC-3 utilization category and supports a motor power capacity of 2.2 kW at 400 V. The device, designated as LC2K0610F7, features a 110 V AC coil operating at 50/60 Hz, along with 1 NO auxiliary contact and a pre-wired reversing circuit.

Measuring 90 mm in width and 57 mm in depth, this compact contactor is compatible with DIN rail mounting. It is designed to withstand mechanical shocks of up to 15 Gn and vibrations, compliant with IEC standards. Its operational temperature range extends from -25 °C to 50 °C, while storage temperatures can vary between -50 °C and 80 °C. The contactor includes robust protective treatments as per IEC 60068 and DIN 50016 standards, achieving an IP20 rating.

This device is preassembled with a reversing power busbar and features a mechanical interlock for enhanced safety. The contactor's electrical durability is rated at 1.3 million cycles at 6 A AC-3, ensuring reliable performance over time. It complies with multiple international standards, including IEC, UL, and CSA, and is recognized as a Green Premium product.
