Schneider Electric XCKMR24SR1H29

The XC Special Range Limit Switch is designed to convert mechanical motion into an electrical control signal, providing actuation by any moving part. This limit switch comes with 2 x (1 normally closed + 1 normally opened), slow-break, break before make contacts without positive opening operation. It features a metal square stay put crossed rods lever and supports lateral approach in two directions. The movement of the operating head is rotary.

This limit switch is equipped with screw clamp terminals for electrical connection, 2 electrical positions, 2 per direction, and 3 entries tapped for M20 x 1.5 cable gland. It is an IP66 and IK07 rated product, suitable for hoisting and mechanical handling applications.

This limit switch has a rated operational current of 3A at 240V AC, 0.55A at 125V AC, and a conventional enclosed thermal current of 10A. It offers long mechanical life with a mechanical durability of about 2 million operating cycles.

The limit switch head and body are made of Zamak. Its dimensions are 200mm (Width) x 59mm (Depth) x 118mm (Height) and weighs 0.55kg. It is suitable for hoisting and mechanical handling applications.

This product is certified by CE, CCC, UL, and CSA. It meets CSA C22.2 No 14, UL 508, and EN/IEC 60947-5-1 standards.
