Wago
812-102
Busbar terminal block; for (10 x 3) mm busbars; without push-buttons; Push-in CAGE CLAMP®; 4,00 mm²; dark gray
- Termin płatności do 90 dni od 500+ dostawców.
- Rabaty na odsprzedaż do 40%!
€49.00
1
Metody płatności:
Łącznie 3 części w magazynie od 11 dostawców
Stan produktu:
Oferta z czasem realizacji przez producenta
Wysyłka:Na zapytanie
Najlepsza cena:
€3.44
Additional Information
- Part Number
- 812-102
- UPC
- 4044918253277
- Tariff Code
- 85369010000
- ETIM
- Group Code : EG000017
- Group Description : Low-voltage Industrial Components
- Class Description : Busbar terminal
- Class Code : EC000001
- Version : 7
Ratings Per Iec/En
- Nominal voltage (III/3)
- 1000 V
- Rated impulse voltage (III/3)
- 6 kV
- Rated current
- 96 A
- Note (rated current)
- Current carrying capacity: With a maximum total current of 96 A, the clamping units of the busbar terminal block can be loaded with the rated current of the conductor cross-sections approved. This only applies when (10 x 3) mm busbars are used.
- Legend (ratings)
- (III / 3) ≙ Overvoltage category III / Pollution degree 3
Environmental Requirements
- Continuous operating temperature
- -35 … +85 °C
Physical Data
- Width
- 75 mm / 2.953 inches
- Height
- 30 mm / 1.181 inches
- Depth
- 27.5 mm / 1.083 inches
Material Data
- Note (material data)
- <a href="https://www.wago.com/us/material-specifications" href="_blank">Information on material specifications can be found here</a>
- Color
- Dark gray
- Material group
- I
- Insulation material
- Polyamide (PA66)
- Flammability class per UL94
- V0
- Fire load
- 0.823 MJ
- Weight
- 35.708 g
Specifications
- Product Group Code
- 0012
Commercial Data
- Packaging type
- Box
- Country of origin
- PL
- GTIN
- 4044918253277
- Customs tariff number
- 85369010000
Connection 1
- Connection technology
- Push-in CAGE CLAMP®
- Actuation type
- Operating tool
- Connectable conductor materials
- Copper
- Solid conductor
- 0.5 … 4 mm² / 20 … 12 AWG
- Solid conductor; push-in termination
- 0.5 … 4 mm² / 20 … 12 AWG
- Stranded conductor
- 0.5 … 4 mm² / 20 … 12 AWG
- Fine-stranded conductor
- 0.5 … 4 mm² / 20 … 12 AWG
- Strip length
- 11 mm / 0.43 inches
- Wiring direction
- Front-entry wiring
