Weidmuller 1875400000

The LSF-SMT 3.81/10/180 1.5SN BK RL is a terminal suitable for printed circuit boards, characterized by its 3.81 mm pitch and a total of 10 poles arranged at a 180° angle. This component utilizes a PUSH IN wire connection method, accommodating a clamping range of up to 1.5 mm². The solder pin length measures 1.5 mm, enabling reliable electrical connections.

Constructed with LCP GF insulating material, the terminal exhibits a black color and meets various industry standards, including IEC 60664-1 and IEC 61984. It is designed for operational temperatures ranging from -50 °C to 120 °C, ensuring functionality in diverse environments. Additionally, it has touch-safe protection according to DIN VDE 0470 and maintains a volume resistance of 1.60 mΩ.

This terminal also complies with multiple certification criteria, including CSA, cURus, and VDE, and holds a UL file number E60693. The dimensions of the terminal include a width of 38.49 mm, a height of 15.5 mm, and a depth of 7.8 mm, with a net weight of 7.834 g. The product family is part of the OMNIMATE Signal series, emphasizing its application in various electronic configurations.
