Weidmuller 1885930000

The presented terminal is designed for printed circuit boards with a pitch of 3.81 mm, accommodating 7 poles at a 135° angle. The terminal is equipped with a solder pin length of 3.5 mm, which is suitable for through-hole or surface mount connections. The maximum clamping range is 1.5 mm², allowing for various wire types including solid and flexible conductors.

In terms of rated data, it adheres to UL 1059 standards with a rated voltage of 300 V and supports a rated current of up to 12 A. Additionally, it has been tested according to IEC 60664-1 and IEC 61984 standards, ensuring reliable performance in various applications.

This terminal's construction includes a black insulating material of LCP GF, with operational elements made of PPA GF. Its comparative tracking index (CTI) is ≥ 175, indicating strong insulation properties. The device operates effectively within a temperature range of -50 °C to 120 °C, making it suitable for diverse environmental conditions.

Approval certifications include CSA, cURus, EAC, and VDE, ensuring compliance with international standards. The terminal is packaged in tubes, facilitating secure handling and storage. Note that the touch-safe protection according to DIN VDE standards is rated at IP 20.
